Tanner Nelson’s MicroPython-based smart sprinkler controller offers a cost-effective alternative to commercial systems. Built on an ESP32 board, it features a web UI, MQTT integration, and customizable scheduling, addressing the need for affordable, flexible irrigation solutions.
Project Overview
Tanner Nelson’s innovative project harnesses the power of ESP32 microcontrollers to create a smart sprinkler system that is both versatile and affordable. The decision to use MicroPython simplifies the coding process while maintaining robust functionality. This project is particularly appealing to DIY enthusiasts and hobbyists interested in home automation and efficient water management.
Essential Components
The core components required for this project include an ESP32 development board, a 16-channel relay board, a step-down buck converter, a 24V transformer, an Amazon Fire HD 8” Tablet, and a 3D-printed container to house the system. These components are chosen for their compatibility and functionality, making the system adaptable to various home setups[1].
Circuit Design and Assembly
The design integrates the ESP32 with a relay board to control multiple zones of irrigation. The step-down buck converter ensures that the ESP32 receives the correct voltage from the 24V transformer. The complete system is enclosed in a custom 3D-printed case, providing both protection and aesthetic appeal. Detailed assembly instructions and design files for the Main Box, Tablet Tray, and Tablet Cover are available to guide users through the construction process[1].
Software and Configuration
Installing MicroPython on the ESP32 involves downloading the specific firmware (version 20240222-v1.22.2) and using esptool.py to flash it. The commands include erasing the flash memory and writing the new firmware. Once installed, users can access the web UI via the IP address 192.168.4.1. The system’s AP mode ensures continued operation during network errors, enhancing reliability[1].
Integration and User Experience
The system’s integration with MQTT allows for seamless communication with home automation systems like Home Assistant. The web UI provides a user-friendly interface for scheduling and monitoring irrigation activities. Screenshots of the interface, including the main menu, scheduler, logs, and settings, showcase the project’s functional design[1].
Conclusion
Tanner Nelson’s ESP32-powered smart sprinkler controller represents a significant advancement in DIY irrigation technology. By combining affordability with extensive customization options, this project empowers users to tailor their irrigation systems to their specific needs. The open-source nature of the project encourages continuous improvement and adaptation by the community.
